Die Head
|
Head Configuration |
cavity |
2 |
|
Die Head Center Distance |
mm |
120 |
|
Product Capacity |
ml |
200-1,000 |
|
Heat Zone |
zone |
12 |
|
Parison Control Points |
units |
100 |
Clamping
|
Clamping Force |
ton |
6 |
|
Clamping Stroke |
mm |
200 |
|
Carriage Stroke |
mm |
400 |
Extruder
|
Screw Diameter |
mm |
45 |
60 |
35 |
35 |
40 |
|
Screw L/D Ratio |
L/D |
24/1 |
24/1 |
24/1 |
24/1 |
24/1 |
|
Extruder Motor |
kw |
7.5KW |
11.25KW |
3.5KW |
2.5KW |
5.625KW |
|
Screw Speed Range |
rpm |
5-60 |
5-60 |
5-60 |
5-60 |
5-60 |
|
Extruding Capacity |
kg/h |
24 |
45 |
10 |
7 |
14 |
|
Heating Zone |
zone |
3+1 |
3+1 |
3+1 |
3 |
2+1 |
|
Blow Air Pressure |
bar |
6~8 |
|
Compressed Air Consumption |
m³/min |
1.5~2 |
|
Machine Net Weight |
ton |
8 |
|
Gross Weight |
ton |
9.5 |
|
Machine Dimension |
m |
4x3.5x3.8 |
|
Total Power |
kw |
87 |
